Drop-in paper loading
Spec
- Printer:Invoice Printer,POS Printer,Receipt Printer
- Type:POS Accessories
Key Features
APPOSTAR thermal printers module of RPM series are able to serve supervised, semisupervised or unsupervised kiosks and vending. It should be automatic ticketing for parking,
passes, theatres, ATMs or public transport , automatic distributors and control access.
- Drop-in paper loading
- USB / RS232
- QR-Code
- Integrated Paper Feed Button and LED
- Simplified Chinese (GB18030)
- ESC / POS Compatibility
Specification
| System | |
| Printing Method | Thermal |
| Number of dots | 384 dots |
| Dot Density | 8 dots / mm |
| Printing Speed | 90 mm / s |
| Interface | RS232, USB |
| Bar Code | UPC-A / E, EAN8, EAN13, CODE39, CODE93,CODABAR, CODE128 and ITF |
| Driver | Windows and OPOS |
| Function Keyboard | Yes |
| Font | KATAKANA, PC437, PC737, PC850, PC851, PC852, PC855, PC858, PC860, PC861, PC862, PC863, PC864, PC866, PC869, PC928, PC3843, PC3844, PC3845, PC3846, WPC1250, WPC1251, WPC1252, WPC1253, WPC1256, WPC1257, Traditional / Simplified Chinese (GB2312), Simplified Chinese (GB18030) Optional |
| Font A | Character Structure: 12 x 24 Number of Columns:48 columns Character Size(WxH):1.5x3.0mm |
| Font B | Character Structure: 9x 17 Number of Columns:64 columns Character Size(WxH):1.1x3.0mm |
| Chinese | Character Structure: 24 x 24 Number of Columns:24 columns Character Size(WxH):3.0x3.0 mm |
| Sensors | |
| Paper Detection | Head-up or Cover-open Detection |
| Temperature Detection | Themistor |
| Paper Consumption | |
| Printing Width | 48 mm |
| Paper Width | 58 mm |
| Max. Paper Thickness | 80u |
| Paper Loading | Easy Loading |
| Maximum Paper Roll Diameter | 32 mm |
| Environment | |
| Operating Temperature | 0°C~45°C |
| Operating Humidity | 10%~90% |
| Mechanical | |
| Mount Size (W x D) | 72.8 x 102.2 mm |
| Dimension(W x D x H) | 76.8 x 77.4 x 45 mm |
| Weight (N.W.) | 67 g |
